Full Automatic Ramen Noodle Making Machine 1000 kg Per hour

Short Description:

HELPER Automatic Ramen /Noodle making machine is based on the traditional handmade noodle making process.The raw materials are only flour, water, salt and eggs, etc., without any food additives.

It adopts Vacuum Dough Mixers equipped with automatic powder and water supply, double-layer or multi-layer noodle-sheet compounding press rollers，multiple waved and flat noodle-sheet rollers, Constant temperature and humidity Noodle-sheet Aging Machine, automatic powder sprinkling, Noodle-string Roll Slitter & cutter and other functions to ensure the original taste of noodles and food safety, realizes the automation, industrial standardization and mass production of noodles.

In addition to producing fresh noodles, frozen cooked noodles, and instant noodles, the HELPER automatic noodle & ramen making machine can be equipped with a skin carving machine and an automatic skin rolling machine., It can also produce dumpling skins, wonton skins, wonton skins, and samosa skins. It is often selected by noodle food factories, supermarkets, and central kitchens.

Applicable Industries: Hotels, Manufacturing Plant, Food Factory, Restaurant, Food & Beverage Shops

Brand: HELPER

Lead Time: 15-20 Working Days

Original: Hebei, China

Payment Method: T/T, L/C

Certificate: ISO/CE/ EAC/

Pacakage Type: Seaworthy Wooden Case

Port: Tianjin/Qingdao/ Ningbo/Guangzhou

Warranty: 1 Year

After-sale Service: Technicians arrive to install/Online Surpport/ Video Guidance

Send email to us

Product Detail

Delivery

About Us

Product Tags

Performance & Features

The entire noodle production line is made of 304 stainless steel to ensure that there will be no food safety problems caused by equipment during noodle production.
The vacuum dough mixer is used to improve the quality and toughness of the dough, reduce the mixing time, and improve production efficiency. In addition, the vacuum dough mixer adopts a U-shaped box to reduce friction heat during dough mixing, greatly reducing the temperature rise caused by mixing during dough mixing;

5. The automatic powder feeding device of the noodle machine is isolated from the production workshop, reducing the amount of dust in the production workshop, and greatly reducing the problem of excessive microorganisms caused by floating dust and water breeding;

7. The rolling part is all driven by a single machine. The chainless direct connection significantly eliminates the generation of noise. The photoelectric switch adjustment of a single group of rolling machines is linked to each other. There is no need to frequently adjust the gap between the rollers when switching between products of different specifications.

8. In addition to being equipped with different noodle knife types, it can also be equipped with a dumpling wrapper forming machine and a wonton wrapper forming machine, making it a multi-purpose machine.

3. Abandon the traditional layout of raising the dough mixer, and adopt a floor-standing dough mixer to facilitate cleaning of the dough mixer and save manpower.

4. PLC automatically controls automatic water and powder feeding technology, which can control the water feeding error within 3‰.

auto-flour-feeding-machine-for-noodle-line

6. The rod-type hanging dough sheet aging machine and the horizontal flat aging machine are available can be choose according to the dough process.

Technical Parameters

Model	Power	Rolling Width	Productivity	Dimension
M-440	35-37kw	440 mm	500-600 kg/h	(12~25)(2.5~6)(2~3.5) m
M-800	47-50 kw	800 mm	1200kg/h	*（14~29）（3.5~8）（2.5~4）*
